Description
A laser level measurement sensor is used for level control, plugged chute detection, and monitoring buildup. The battery-powered laser removes the complexity and expenses of wiring during install and allows installation in locations where inventory monitoring was not previously feasible. The laser can be mounted on an adjustable swivel mount or a fixed mounting plate and can be programmed to take interval readings from once per hour to once a day. Through the use of a LoRa transceiver and modem, the sensor data can be easily accessed by a phone, tablet, or PC for data monitoring and alerts.
Features & Benefits
- Battery-Powered simplifies installation and eliminates wiring
- Long Battery Life of 3 to 5 years depending on frequency of measurement
- Single Point measurement at distances up to:
- Model SPL-200: 98 feet
- Model FVL-200: 35 feet
- Visible red laser for aiming that is safer than invisible laser
- LoRa transceiver for reliable long-range data communications
- 1.5″ NPT threaded mounting with fixed or adjustable mounting plates
- Programmable time intervals for sending measurement data
- Dust tube protects laser from buildup to minimize maintenance
