Kurz 2445 High Temperature Probe Portable Flow Meter

The Model 2445 Portable Velocity Meter is a rugged, portable air velocity meter for a wide variety of very high temperature (500°C) industrial applications. The Model 2445 is mainly used for velocity, flow rate and temperature traverse measurements in larger pipes, ducts and stacks. Most applications are coal-fired power plant stacks, primary and secondary air ducts. The Model 2445 has a fixed length 3/4″ diameter sensor support and is rated at 500°C. The exclusive Kurz “FD-HHT” sensor with mineral-insulated (MI) sensor cable is used within the sensor support. Because of its rugged all-welded construction and larger size, the Model 2445 can be used in dirty and corrosive environments. The active sensor support is rated for 500°C; the “handle” is rated for 200°C. Extension handles may be added, but must be kept below 200°C in order to protect the sensor cable.

Features & Benefits

• Easy-to-use menu for display and set-up with HELP screens
• Two-line 16 character, back0lit LCD with twenty button keypad
• User selected scrolling display
• 24-hour clock/calendar (4 digit year display)
• Two optically isolated loop-powered 4-20mA outputs. User selected for velocity, flow rate or temperature (optional)
• 1500 Point Data Memory for recording traverses and other measurements
• Multi-Point calibration correction factors for Flow and Temperature
• User-entered METER-ID number
• User-entered flow area
• User selected Reference Conditions (STP)
• User selected low Velocity cut-off
• User selected RS-232C or RS-485 serial port for terminal operation (optional)
• Fastest response to temperature and velocity changes available
• Electronics operating temperature range of -25C to 65C , non-condensing
• Low velocity sensitivity
• .25% repeatability
• High accuracy over wide velocity and temperature range
